KSP2FRPP
Where to Buy

The Kingray KSPxF series of splitters are designed for peak performance across the entire terrestrial & satellite bands up to 2400 MHz. These A class splitters are compact in design with excellent screening characteristics & are Foxtel Approved. The KSP2FRPP & KSP4FRPP have been specifically designed for use in a multistacker system. With these splitters, it allows the installer to remotely power up to 4 Active Taps with the use of a PIK2400 & a power supply such as the PSK124F or PSK183F.

Product Details


Key Features

  • Frequency Range 5-2400 MHz
  • 1 Input
  • 2 Outputs
  • Reverse Power Pass All Ports - In to Out Ports
  • 2A DC Maximum Throughput
  • Insertion Loss: 4dB @ 5 MHz, 5.5dB @ 2400 MHz
  • Return Loss: >10dB
  • Connectors: F-Type

In the box

  • 2 Way F-Type Splitter Reverse Power Pass All Ports
  • Mounting Screws
